Precision Grinding offers a variety of precision ground table tops and precision machined table tops for industrial companies. PGI Steel is 'The Single Source Solution for Custom Steel Plate.' Contact Us Today! 1-888-934-7463 or mail@pgisteel.com. Home / Custom Steel Plate / Precision Table. Tilting Table Angle Plate for Milling Machines with Crank Handle T-slots 12'x9' Product Description. Material: cast iron. Specification: 12 inches. Dimensions: 300.230.170 (mm) T-slot. Pivot the plate to expose the T-Slots on the right side of the table. Pivoting is easy with the oil slick of rust preventative! Install 3 T-Slot Nuts, one in each slot. Position the top and bottom at the right end of the T-Slot. Slide the middle one as close to center as you can reach. Pivot the other way to expose the T-Slots on the left side. The PT25 ALuminum Exutrusions table plates have t-slots on one side only. The t-slots are on 25mm centers. They are clear anodized for a clean and durable finish; The extrusion is stress relieved and both sides are machined flat. It comes in 3 widths - 125mm, 250mm and 375mm and can be used to make very flat anf precise work beds, fixture plates, table tops, etc. Can be provided cut to custom lengths for OEM quantities.
PGI Steel offers a variety of precision ground and precision machined table tops for industrial companies.
- Custom Steel Table Top 1/4″ – 2″ thick A36, 1020, hot-rolled steel, 4140
- Strong tubular steel frame choices
- Also Available: Side Frames from Plate 2″, 3″, 4″, other
- Any Fabricated Frame Leveling feet or leveling pads available
- Adjustable Level Feet Large CNC Machining / Vertical Milling 31″ x 78″ x 122″ CNC
- Blanchard Rotary Grinding to 45″ tall
- Blanchard Reciprocating Grinders 128″ diagonal grinding 14″ x 48″ x 200″
- Painted or unfinished fabrications
- Machine Enamel, Epoxy or Powder Coat Precision Steel Tables, any size/grade.
- Machine Base Pedestal
- Machined Steel Table Top
- Robotics Platform
- Machine Table Base
- Industrial Steel Machine Table
T Slot Bed Plate
We offer a complete selection of steel processing services:
- Plate Cutting
- Grinding
- CNC Machining
- Steel Fabricating
- Flame & Plasma Cutting large and thick plate burnouts
- Precision Surface Grinding to close tolerances
- Precision Machining on large capacity
- Machines & Mills
- Burning, Welding, Forming, Assembly, Fabrication
Grinding & Machining large and thick steel plates: Fluid grooves, channels, lips, contoured lines & beveling available. Complex holes, recessed cut-outs, shaping & insets available.
Machine Table Tops: any thickness cut, ground, machined. Our precision steel tables are sturdy, rugged, and built to last.
Dyne Systems offers a variety of different Dyno Testing Tables and Testing Stands suited for your specific testing needs. From Horizontal Test Stands, Vertical Test Stands, Tilt Tables, T-Slot Tables to various XYZ Tables. If you can’t find what your looking for below, give us a call and we can build a table or test stand for your specific testing application.
Vertical / Horizontal Test Stands:
Built for testing small engines and electric motors with both vertical and horizontal shaft orientations. Changing orientation of the dynamometer is accomplished via an electric actuator and the dynamometer can then be mechanically locked vertically or horizontally. The Vertical/Horizontal Test Stand can be configured with a eddy current (absorbing) dynamometer or an AC (motoring and absorbing) dynamometer depending on the application.
Tilt Tables:
The Tilt Table allows for a Device Under Test (DUT) to be orientated at various angles of incline or decline. This can assist in the simulation of extreme conditions to evaluate the performance of components such as transmissions/gearboxes.
T-Slot Tables:
Constructed of tubular steel with a Blanchard Ground mounting surface, table top features machined T-Slot grooves for mounting fixtures and device under test (keyways and other grooves also available). Leveling vibration dampeners on table leg bottoms are included. Other dimensional configurations are available upon request.
Aluminum T Slot Table
XYZ Lift Table Test Stands:
For the testing of electrical motors with varied horizontal or vertical center lines. It features a fixture mounting plate that can be adjusted on the X-Y-Z axes. The X and Z axes are controlled through manual crank handles while the Y axis is adjusted through a remote pendent which controls a hydraulic scissors lift.
Need a Custom Eddy Current Dynamometer Test Stand?
T Slotted Aluminum Plate
Contact our engineering experts today.
